FEATURES
Standard Grip Sheet tie sheets are available in basic paper weights from 60g/m2 to 300g/m2. In some applications, this just isn’t enough. ENDUPACK offers the Grip Pad for the most demanding applications.
 Heavy water bottles are stacked on a pallet using a thick chipboard Grip Pad. |  Heavy weight rolls are being shipped on pallets doubled stacked using a Grip Pad between the two pallets |  Heavy weight rolls are being shipped on pallets doubled stacked using a Grip Pad between the two pallets |  Lightweight empty plastic bottles in plastic bags are being stacked 8 layers per pallets and 2 pallets high using Grip Pad for internal storage. |
BENEFITS
- Non-slip properties
- Very strong
- Reusable and recyclable
SPECIFICATIONS
On the top
e-flute corrugated board
0.075” (2 mm) thick
In the middle
Chipboard*
0.05” (1,3 mm) thick
Below
Chipboard*
0.160’’ (4 mm) thick
Grip Pad E-flute Corrugated Board Standard Stock Product
Sheet size : 47.25” X 39.4” (1200 mm X 1000 mm)
Available thicknesses: 0.075” (2 mm)
Grip Sheet non-slip coating: 100% 2 sides or alternate stripes
Material: medium et liners recyclés
Quantity per pallet: 500
Grip Pad Chipboard* 2 sides coated
Sheet size : Up to 60” X 120” (2,3 m X 4,6 m)
Available thicknesses: 0.05” to 0.165” (1,3 mm to 4,4 mm)
Grip Sheet non-slip coating: 100% 2 sides, waterproof finish available
Material: Dry finish chipboard 100% recycled
Quantity per pallet: As per specification
Grip Pad Chipboard* 1 side coated
Sheet size : Up to 60” X 120” (2,3 m X 4,6 m)
Available thicknesses: 0.085” to 0.16” (2,2 mm to 4 mm)
Grip Sheet non-slip coating: 100% 1 side, top or bottom, waterproof finish available
Material: Dry finish chipboard 100% recycled
Quantity per pallet: As per specification
* Chipboard versions of GripPad are made in Canada.
DOCUMENTATION
Chipboard
Corrugated board
